This fireplace is startling in size and is a logical and environmentally friendly option for any homeowner looking to combine style and high efficiency. Choose from four beautiful faceplate louvers to personalize your home.
What’s Included
- 50″ Wood Fireplace
- Black Arched Faceplate
- Classic Moulded Refractory Bricks
- Classic Style Faceplate Louver
- Double Doors with Ceramic Glass
- Stainless-steel secondary-air system improving gas combustion
Not Included (Sold Separately)
- 5ӯ Fresh Air Intake Register With Airtight Damper
- 6″Ø X 25′ Insulated Flex Pipe For Forced Air Kit
- Warm Air Circulation Grille – Modern
- Glass Hearth Pad
- Non-Combustible Mantel
- Forced Air Kit
Features
- Large wood fireplace — Behind its large glass door, the 4.3 cubic foot combustion chamber can hold an impressive 60 lbs. of wood.
- Low emissions — This energy-efficient fireplace complies with the EPA’s clean-air standards with only 1.6 g/h of emission.
- High efficiency — The FP15A fireplace is capable of heating large spaces and burns for 10 hours.
- Performance Fireplaces for High Efficiency — This line offers fireplaces with eco-friendly heating with emissions below the limits imposed by EPA and the benefits of an efficient overnight burn. If needed, they can be used for ambiance with the doors open.
Specifications
| Model Number | FP15A |
| UPC | 773388171616 |
| Combustion technology | Non-catalytic |
| High-efficiency EPA certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 25″ |
| Log positioning | Over width |
| Chimney diameter | 8″ |
| Flue outlet diameter | 8″ |
| Type of chimney | CAN/ULC S604, UL 103 (1700 °F) – CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 15′ |
| Baffle type | C-Cast |
| Approved for a mobile home installation | No |
| Shipping Weight | 545 lb (247 kg) |
| Door type | Double, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 29 3/4″ X 13″ |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 176 |
| Overall dimension (Height) | 43 3/8″ |
| Overall dimension (Width) | 50 3/4″ |
| Overall dimension (Depth) | 31 5/8″ |
| Door opening – dimension (Height) | 12 3/4″ |
| Door opening – dimension (Width) | 33″ |
| Firebox – dimension (Height) | 17″ |
| Firebox – dimension (Width) | 25 3/8″ |
| Firebox – dimension (Depth) | 17 7/8″ |
| Moulded refractory bricks |
Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| USA standard (emissions) | EPA / ASTM WK47329 |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 127 |
| Canadian standard (safety) | ULC-S610 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
Appliance Performance
⁽¹⁾Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. ⁽⁾Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure. ⁽²⁾The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%. ⁽³⁾As measured per CSA B415.1-10 stack loss method. ⁽⁴⁾Higher Heating Value of the fuel. ⁽⁵⁾Lower Heating Value of the fuel. ⁽⁶⁾Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%. ⁽⁷⁾Optimum overall efficiency at a specific burn rate (LHV). ⁽⁸⁾This appliance is officially tested and certified by an independent agency. ⁽⁹⁾Carbon monoxyde. |
Approved Chimney Types
*Specific components may be required depending on the chimney manufacturer. |
Minimum clearances to combustibles*(Data expressed in inches. 1 inch = 25.4 mm)
*The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner’s manual, catalogues, flyers, magazines and/or web sites). |
